值分布强化学习 C51

时间：2026-02-16 10:02:24

值分布强化学习是基于价值的强化学习算法，不同于传统方法仅建模累积回报期望值，它对整个分布Z(s,a)建模以保留分布信息。C51是其代表算法，将分布离散为51个支点，输出支点概率，通过投影贝尔曼更新处理分布范围问题，损失函数用KL散度，框架与DQN类似但输出和更新方式不同。

值分布强化学习简介

首先需要声明的是，值分布强化学习（Distributional Reinforcement Learning）是一类基于价值的强化学习算法（value-based Reinforcement Learning）

经典的价值式强化学习方法采用期望值模型来模拟累积回报，定义为价值函数 V(s) 和动作价值函数 Q(s,a)。

而在这个建模过程中，完整的分布信息在很大程度上被丢失了

提出值分布强化学习旨在处理分布信息缺失问题，以Z(s, a)表示累积回报随机变量的整体分布，而非仅建模其期望。

如果用公式表示:

Q(st,at)=EZ(st,at)=E[∑i=1∞γt+iR(st+i,at+i)]Q(st,at)=EZ(st,at)=E[i=1∑∞γt+iR(st+i,at+i)]

值分布强化学习C51算法

C51 简介

值分布视角下的增强学习算法C算法源自 DeepMind 的论文A Distributional Perspective on Reinforcement Learning一文。在这篇文章中，作者首先指出传统 DQN 算法所希望学习的是一个数值 Q值，代表了未来奖励的期望值。但在系列算法的背景下，目标被改变了，它转变为了一个分布。在这一视角下，Q值被转换成了一个随机变量 Z。这种转变不仅增加了模型学习的内容，还使得学到的信息不再是仅仅数值化的形式，而是包含了整个分布。因此，模型返回的损失函数也从对数值 Q值与期望奖励之间的差异进行度量，转变为两个分布之间相似度的度量（metric）。这一改变使 C算法不仅能够处理数值问题，还能够在一定程度上解决复杂的概率和分布问题，从而在强化学习中表现出色。

算法关键

参数化分布

简而言之，若分布取值范围为VminVmin到VmaxVmax，并均分为离散的N个点，每个等分支集为

{zi=Vmin+iΔz:0≤iN,Δz=VmaxVminN1}{zi=Vmin+iΔz:0≤i

模型输出的每个值对应取当前支点的概率

投影贝尔曼更新

通过贝尔曼操作符处理后的新随机变量取值范围可能会超出其所在支点中离散化集合的边界，如图示。

为了确保在离散化后准确反映贝尔曼迭代结果，我们需要将更新后的随机变量投影到支集上，这与论文中提到的方法一致。

简单来说，投影过程就是将更新后随机变量的值分配到与其相邻的支点上

小结

C51算法与DQN相同点

C法的基础架构依旧遵循DQN原则；采样环节保持了贪心策略；这里的“贪婪”是指采取期望最大化策略。此外，引入了一个独立的目标网络来优化决策过程。

C51算法与DQN不同点

C51算法的卷积神经网络的输出不再是行为值函数，而是支点处的概率。

C51算法的损失函数不再是均方差和而是如上所述的KL散度

最后一个问题，该算法为什么叫C51呢？

这是因为在论文中，作者将随机变量的取值分成了51个支点类。

代码部分

导入依赖

In [1]

from typing import Dict, List, Tupleimport gymfrom visualdl import LogWriterfrom tqdm import tqdm,trangeimport numpy as npimport paddleimport paddle.nn as nnimport paddle.nn.functional as Fimport paddle.optimizer as optimizer登录后复制

需要用到的特殊算子

In [2]

def index_add_(parent, axis, idx, child): expend_dim = parent.shape[0] idx_one_hot = F.one_hot(idx.cast("int64"), expend_dim) child = paddle.expand_as(child.cast("float32").unsqueeze(-1), idx_one_hot) output = parent + (idx_one_hot.cast("float32").multiply(child)).sum(axis).squeeze() return output登录后复制

经验回放

In [3]

class ReplayBuffer: def __init__(self, obs_dim: int, size: int, batch_size: int = 32): self.obs_buf = np.zeros([size, obs_dim], dtype=np.float32) self.next_obs_buf = np.zeros([size, obs_dim], dtype=np.float32) self.acts_buf = np.zeros([size], dtype=np.float32) self.rews_buf = np.zeros([size], dtype=np.float32) self.done_buf = np.zeros([size], dtype=np.float32) self.max_size, self.batch_size = size, batch_size self.ptr, self.size, = 0, 0 def store( self, obs: np.ndarray, act: np.ndarray, rew: float, next_obs: np.ndarray, done: bool, ): self.obs_buf[self.ptr] = obs self.next_obs_buf[self.ptr] = next_obs self.acts_buf[self.ptr] = act self.rews_buf[self.ptr] = rew self.done_buf[self.ptr] = done self.ptr = (self.ptr + 1) % self.max_size self.size = min(self.size + 1, self.max_size) def sample_batch(self): idxs = np.random.choice(self.size, size=self.batch_size, replace=False) return dict(obs=self.obs_buf[idxs], next_obs=self.next_obs_buf[idxs], acts=self.acts_buf[idxs], rews=self.rews_buf[idxs], done=self.done_buf[idxs]) def __len__(self): return self.size登录后复制

定义网络结构

尽管我们的DQN能掌握游戏的所有分布，但在CartPole-v境下，仍以期望为决策准则。

与传统的 DQN 相比，我们的 C51 会在更新方式上有所不同。 In [4]

class C51DQN(nn.Layer): def __init__( self, in_dim: int, out_dim: int, atom_size: int, support ): # 初始化 super(C51DQN, self).__init__() self.support = support self.out_dim = out_dim self.atom_size = atom_size self.layers = nn.Sequential( nn.Linear(in_dim, 128), nn.ReLU(), nn.Linear(128, 128), nn.ReLU(), nn.Linear(128, out_dim * atom_size) ) def forward(self, x): dist = self.dist(x) q = paddle.sum(dist * self.support, axis=2) return q def dist(self, x): q_atoms = self.layers(x).reshape([-1, self.out_dim, self.atom_size]) dist = F.softmax(q_atoms, axis=-1) dist = dist.clip(min=float(1e-3)) # 避免 nan return dist登录后复制

Agent 中涉及到的参数设定

Attribute:env: gym 环境memory: 经验回放池的容量batch_size: 训练批次epsilon: 随机探索参数epsilonepsilon_decay: 随机探索参数epsilon衰减的步长max_epsilon: 随机探索参数epsilon上限min_epsilon: 随机探索参数epsilon下限target_update: 目标网络更新频率gamma: 衰减因子dqn: 训练模型dqn_target: 目标模型optimizer: 优化器transition: 转移向量，包含状态值state, 动作值action, 奖励reward, 次态next_state, （判断是否）结束回合donev_min: 离散支集的上限v_max: 离散支集的下限atom_size: 支点数量support: 支集模板（用于计算分布的向量模板）登录后复制 In [5]

class C51Agent: def __init__( self, env: gym.Env, memory_size: int, batch_size: int, target_update: int, epsilon_decay: float, max_epsilon: float = 1.0, min_epsilon: float = 0.1, gamma: float = 0.99, # C51 算法的参数 v_min: float = 0.0, v_max: float = 200.0, atom_size: int = 51, log_dir: str = "./log" ): obs_dim = env.observation_space.shape[0] action_dim = env.action_space.n self.env = env self.memory = ReplayBuffer(obs_dim, memory_size, batch_size) self.batch_size = batch_size self.epsilon = max_epsilon self.epsilon_decay = epsilon_decay self.max_epsilon = max_epsilon self.min_epsilon = min_epsilon self.target_update = target_update self.gamma = gamma self.v_min = v_min self.v_max = v_max self.atom_size = atom_size self.support = paddle.linspace( self.v_min, self.v_max, self.atom_size ) # 定义网络 self.dqn = C51DQN( obs_dim, action_dim, atom_size, self.support ) self.dqn_target = C51DQN( obs_dim, action_dim, atom_size, self.support ) self.dqn_target.load_dict(self.dqn.state_dict()) self.dqn_target.eval() self.optimizer = optimizer.Adam(parameters=self.dqn.parameters()) self.transition = [] self.is_test = False self.log_dir = log_dir self.log_writer = LogWriter(logdir = self.log_dir, comment= "Categorical DQN") def select_action(self, state: np.ndarray): if self.epsilon > np.random.random(): selected_action = self.env.action_space.sample() else: selected_action = self.dqn( paddle.to_tensor(state,dtype="float32"), ).argmax() selected_action = selected_action.detach().numpy() if not self.is_test: self.transition = [state, selected_action] return selected_action def step(self, action: np.ndarray): next_state, reward, done, _ = self.env.step(int(action)) if not self.is_test: self.transition += [reward, next_state, done] self.memory.store(*self.transition) return next_state, reward, done def update_model(self): samples = self.memory.sample_batch() loss = self._compute_dqn_loss(samples) self.optimizer.clear_grad() loss.backward() self.optimizer.step() loss_show = loss return loss_show.numpy().item() def train(self, num_frames: int, plotting_interval: int = 200): self.is_test = False state = self.env.reset() update_cnt = 0 epsilons = [] losses = [] scores = [] score = 0 epsilon = 0 for frame_idx in trange(1, num_frames + 1): action = self.select_action(state) next_state, reward, done = self.step(action) state = next_state score += reward # 回合结束 if done: epsilon += 1 state = self.env.reset() self.log_writer.add_scalar("Reward", value=paddle.to_tensor(score), step=epsilon) scores.append(score) score = 0 if len(self.memory) >= self.batch_size: loss = self.update_model() self.log_writer.add_scalar("Loss", value=paddle.to_tensor(loss), step=frame_idx) losses.append(loss) update_cnt += 1 self.epsilon = max( self.min_epsilon, self.epsilon - ( self.max_epsilon - self.min_epsilon ) * self.epsilon_decay ) epsilons.append(self.epsilon) if update_cnt % self.target_update == 0: self._target_hard_update() self.env.close() def test(self): self.is_test = True state = self.env.reset() done = False score = 0 frames = [] while not done: frames.append(self.env.render(mode="rgb_array")) action = self.select_action(state) next_state, reward, done = self.step(int(action)) state = next_state score += reward print("score: ", score) self.env.close() return frames def _compute_dqn_loss(self, samples: Dict[str, np.ndarray]): # 计算损失 state = paddle.to_tensor(samples["obs"],dtype="float32") next_state = paddle.to_tensor(samples["next_obs"],dtype="float32") action = paddle.to_tensor(samples["acts"],dtype="int64") reward = paddle.to_tensor(samples["rews"].reshape([-1, 1]),dtype="float32") done = paddle.to_tensor(samples["done"].reshape([-1, 1]),dtype="float32") delta_z = float(self.v_max - self.v_min) / (self.atom_size - 1) with paddle.no_grad(): next_action = self.dqn_target(next_state).argmax(1) next_dist = self.dqn_target.dist(next_state) next_dist = next_dist[:self.batch_size,] _next_dist = paddle.gather(next_dist, next_action, axis=1) eyes = np.eye(_next_dist.shape[0], _next_dist.shape[1]).astype("float32") eyes = np.repeat(eyes, _next_dist.shape[-1]).reshape(-1,_next_dist.shape[1],_next_dist.shape[-1]) eyes = paddle.to_tensor(eyes) next_dist = _next_dist.multiply(eyes).sum(1) t_z = reward + (1 - done) * self.gamma * self.support t_z = t_z.clip(min=self.v_min, max=self.v_max) b = (t_z - self.v_min) / delta_z l = b.floor().cast("int64") u = b.ceil().cast("int64") offset = ( paddle.linspace( 0, (self.batch_size - 1) * self.atom_size, self.batch_size ).cast("int64") .unsqueeze(1) .expand([self.batch_size, self.atom_size]) ) proj_dist = paddle.zeros(next_dist.shape) proj_dist = index_add_( proj_dist.reshape([-1]), 0, (l + offset).reshape([-1]), (next_dist * (u.cast("float32") - b)).reshape([-1]) ) proj_dist = index_add_( proj_dist.reshape([-1]), 0, (u + offset).reshape([-1]), (next_dist * (b - l.cast("float32"))).reshape([-1]) ) proj_dist = proj_dist.reshape(next_dist.shape) dist = self.dqn.dist(state) _dist = paddle.gather(dist[:self.batch_size,], action, axis=1) eyes = np.eye(_dist.shape[0], _dist.shape[1]).astype("float32") eyes = np.repeat(eyes, _dist.shape[-1]).reshape(-1,_dist.shape[1],_dist.shape[-1]) eyes = paddle.to_tensor(eyes) dist_batch = _dist.multiply(eyes).sum(1) log_p = paddle.log(dist_batch) loss = -(proj_dist * log_p).sum(1).mean() return loss def _target_hard_update(self): # 更新目标模型参数 self.dqn_target.load_dict(self.dqn.state_dict())登录后复制

定义环境

In [6]

env_id = "CartPole-v0"env = gym.make(env_id)登录后复制

设定随机种子

In [7]

seed = 777np.random.seed(seed) paddle.seed(seed) env.seed(seed)登录后复制

[777]登录后复制

超参数设定与训练

In []

num_frames = 20000memory_size = 1000batch_size = 32target_update = 200epsilon_decay = 1 / 2000# 训练agent = C51Agent(env, memory_size, batch_size, target_update, epsilon_decay) agent.train(num_frames)登录后复制

- | | 32/20000 [00:00<01:38, 202.97it/s]登录后复制
